5052 Aluminum Coil
5000 series

5052 Aluminum Coil

Alloy:5052
Temper:HO-H321
Width:100-2600mm
Thickness:0.2-8.0mm
Coil ID:75mm, 150mm, 200mm, 300mm, 400mm, 508mm or customized
Coil OD:per customer’s request
Surface:Mill finished and silvery aluminum,color coated, anodized, mirror finish,diamond , tread, brushed, wood grain, stucco embossed
Port of Loading:Qingdao or customized
Delivery Time:15-25 days
Certificated:ISO9001:2015,SGS,SABER


Share:
Introduction
The 5052 aluminum coil is an alloy made up of 2.5 percent magnesium and 0.25 percent chromium. It’s considered to have great workability and weldability. It has medium static and high fatigue strength. The corrosion resistance of this aluminum is very good, especially in marine environments. This metal has excellent thermal conductivity and low density, like with other aluminum alloys. To harden aluminum 5052, cold working can be used. Heat treatment cannot be used to obtain higher alloy strength.
The fatigue properties of this aluminum are excellent, with a limit of 115 MPa while in the H32 temper and 123 MPa while in H34 temper. Compared to the other aluminum alloys, the 5052 grade of aluminum has midway alloying content and strength. In slightly alkaline environments, 5052 alloys show a resistance level. Its resistance to marine environments is better than that of 5005 alloys, making it a more popular choice for marine applications.
DATA
Chemical Elements and Content(max)
Alloy Si Fe Cu Mn Mg Cr Zn Others Al
5005 0.4 0.4 0.2 0.2 0.5-1.1 0.1 0.25   Remains
5050 0.4 0.7 0.2 0.1 1.1-1.8 0.1 0.25   Remains
5052 0.45 (Si+Fe) 0.1 0.1 2.2-2.8 0.15-0.35 0.1   Remains
5056 0.3 0.4 0.1 0.05-0.2 4.5-5.6 0.05-0.2 0.1   Remains
5083 0.4 0.4 0.1 0.3-1.0 4.0-4.9 0.05-0.25 0.25   Remains
5086 0.4 0.5 0.1 0.2-0.7 3.5-4.5 0.05-0.25 0.25   Remains
5154 0.45 (Si+Fe) 0.1 0.1 3.1-3.9 0.15-0.35 0.2   Remains
5205 0.15 0.7 0.03-0.1 0.1 0.6-1 0.1 0.05   Remains
5252 0.08 0.1 0.1 0.1 22-2.8       Remains
5254 0.45 (Si+Fe) 0.05 0.1 3.1-3.9 0.15-0.35 0.2   Remains
5356 0.50 (Si+Fe) 0.1 0.05-0.2 4.5-5.5 0.05-0.2 0.1   Remains
5357 0.12 0.17 0.2 0.15-0.45 0.8-1.2       Remains
5454 0.4 (Si+Fe) 0.1 0.5-1 2.4-3 0.05-0.2 0.25 Ti0.2 Remains
5456 0.4 (Si+Fe) 0.1 0.5-1 47-5.5 0.05-0.2 0.25 Ti0.2 Remains
5457 0.08 0.1 0.2 0.15-0.45 0.8-1.2       Remains
5652 0.4 (Si+Fe) 0.04 0.1 2.2-2.8 0.15-0.35 0.1   Remains
5657 0.08 0.1 0.1 0.03 0.6-1   0.03   Remains
Packaging and Delivery
5052 aluminum coil of Henan Kailong Aluminum. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 20-28 tons in 1×20′ container(20ft GP:5898mm(Length)x2352mm(Width)x2393mm(Height).
Application
5052 is used in a wide range of atmospheric environments, including food and architectural applications and in many marine environments. The magnesium content is low enough that it does not suffer from the stress corrosion cracking that can affect alloys with more than about 3.5% Mg. Alloy 5052 is also used for consumer electronics casings, notebook computers and televisions.
Bus body
Bus body
Kitchen sink
Kitchen sink
Fan blades
Fan blades
