1050 Aluminum Coil from China Manufacturer

Introduction

1050 Aluminum Coil Introduction and Applications
1050 belongs to Type 1 pure aluminum (Al ≥ 99.50%), which is a commonly used pure aluminum coil in industry. It has excellent properties in forming, electrical conductivity and heat conductivity, corrosion resistance, and a moderate cost. It is supplied in coil form, facilitating continuous stamping, bending, cutting and coating processes.
I. Basic Characteristics
• Alloy grade: 1050/1050A, pure aluminum series, not heat-treatable strengthened
Common states: O state (soft state, easy to stretch and bend), H14/H18/H24 (semi-hard/hard state, maintains shape and is not prone to deformation)
• Core Advantage
Excellent plasticity, easy for stamping, stretching, spinning and bending processes.
2. Excellent electrical and thermal conductivity, second only to 1060/1070.
3. Excellent resistance to atmospheric corrosion. The surface can be oxidized, polished or sprayed.
4. Excellent welding performance, no risk of stress cracking
5. High cost-performance ratio, suitable for large-scale processing
• Standard thickness: 0.2 - 3.0mm (most commonly used), width can be cut to order as needed

DATA

	Chemical Elements and Content(max)
Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Ni	Al	Others
1050	0.25	0.4	0.05	0.05	0.05	-	0.05	0.03	-	99.5	-
1060	0.25	0.35	0.05	0.03	0.03	-	0.05	0.03	-	99.6	-
1070	0.20	0.25	0.03	0.03	0.03	-	0.07	0.03	-	99.7	-
1080	0.15	0.15	0.03	0.02	0.02	-	0.06	0.02	-	99.8	-
1100	0.25	0.4	0.05	0.05	0.05	-	0.05	0.03	0.1	99.5	-
1145	0.55	0.55	0.05	0.05	0.05	-	-	0.03	-	99.45	-
1200	1	1	0.5	0.5	-	-	0.05	0.05	0.1	99	-
1235	0.65	0.65	0.5	0.5	0.5	-	0.1	0.06	0.1	99.35	-

Packaging and Delivery

1050 aluminum coil of henan Kailong Aluminum. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 20-28 tons in 1×20′ container.

Application

II. Typical Applications
Lighting fixtures / Reflective products
• Applications: Lamp covers, reflective covers, tube light housings, street lamp accessories, LED reflective plates
• Compatibility: 0.4 - 1.2mm, O/H14 state, utilizing high reflectivity and easy formability
2. Household Appliances and Electronic Accessories
• Application: Inner and outer shells of rice cookers and electric kettles, heat dissipation plates, motor end caps, and electrical enclosures/insides.
• Compatibility: 0.5 - 2.0mm, O/H14 state, balance of formability and structural strength
3. Signs/Decorations/Hardware Components
• Applications: Metal nameplates, identification plates, decorative panels, hardware stamping accessories, curtain wall decorative components
• Compatibility: 0.3 - 1.5mm, H14/H24 state, not prone to deformation, easy to print/oxidize
4. Deep drawn parts for cooking utensils / kitchenware
• Application: Lightly stretched tableware, kitchen accessories, small aluminum containers, steaming trays / baking trays
• Compatibility: 0.8 - 2.0mm, O state, excellent deep drawing forming property
5. Heat Conduction/Dissipation Components
• Applications: Radiator, heat pad, air conditioning cooling components, heat exchanger assemblies
• Compatibility: 0.3 - 1.0mm. Thin materials are conducive to heat conduction and bending.
6. Container/Packaging/General Shell
• Applications: Small aluminum cans, sealing caps, instrument housings, pipe heads, industrial packaging liners
• Compatibility: 1.0 - 2.5mm, O/H14 state, corrosion-resistant + good formability
7. Electricians / Conductive Components
• Application: Busbar, conductive gasket, terminal block, electrical grounding piece
• Compatibility: 0.5 - 2.0mm, utilizing excellent conductivity
